DESCRIPTION:

This Service Manual describes the operation, maintenance, and overhaul procedures for the Allison 1000 & 2000 Series Transmissions. Describes major components, power flows, hydraulic system function/operation, torque specs, wear limits, inspection procedures. Includes cross sections, exploded views and hydraulic charts.

MODEL COVERAGE:

- Allison 1000 Series
- Allison 2000 Series

TYPICAL CONTENTS:

- General Information
- Description & Operation
- Preventative Maintenance
- General Overhaul Information
- Disassembly of Transmission
- Rebuild of Subassemblies
- Assembly of Transmission
- Wear Limits and Spring Data
- Fold Out Cross-Section Views, Schematic Views and Exploded Views
