2013 - 2018 Honda CBR500R/RA, CB500F/FA & CB500X/XA Factory Service Manual - OEM

This a Genuine, OEM Factory Service Manual. This manual describes the detailed, step-by-step service, repair, troubleshooting & overhaul procedures for the 2013 - 2018 Honda CBR500R/RA, CB500F/FA & CB500X/XA Motorcycles. This is the same manual used in your local Honda dealership by certified Honda Technicians.

MODEL COVERAGE:

• Honda CBR500R/RA: 2013 - 2018
• Honda CB500F/FA: 2013 - 2018
• Honda CB500X/XA: 2013 - 2018

TYPICAL TABLE OF CONTENTS:

• General Information
• Frame / Body Panels / Exhaust System
• Maintenance
• Lubrication System
• Fuel System
• Cooling System
• Engine Removal / Installation
• Cylinder Head / Valves
• Cylinder / Piston
• Drive and Driven Pulleys / Clutch
• Alternator / Starter Clutch
• Crankcase / Crankshaft
• Front Wheel / Suspension / Steering
• Rear Wheel / Brake / Suspension
• Hydraulic Disc Brake
• Battery / Charging System
• Ignition System
• Electric Starter
• Lights / Meters / Switches
• Wiring Diagram
• Troubleshooting
• Index
