2008 - 2019 Honda XR650L Factory Service Manual - Reprint

Brand New Honda Factory Service Manual - Licensed Reproduction

This service manual describes the service procedures for the Honda XR650L Motorcycles.

Model Coverage:

XR650L: 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019

Typical Table of Contents:

• General Information
• Frame/Body Panels/Exhaust System
• Maintenance
• Lubrication System
• Fuel System
• Engine Removal/Installation
• Cylinder Head/Valves
• Cylinder/Piston
• Clutch/Gearshift Linkage
• Alternator/Starter Clutch
• Crankshaft/Transmission
• Front Wheel/Suspension/Steering
• Rear Wheel/Brake/Suspension
• Hydraulic Brake
• Battery/Charging System
• Ignition System
• Electric Starter
• Lights/Meter/Switches
• Wiring Diagrams
• Troubleshooting
• Index
