2010 - 2020 Kawasaki KLX110/L Cyclepedia Motorcycle Service Manual

This Cyclepedia Press motorcycle service manual provides repair information for Kawasaki KLX110 & KLX110L off-road mini-bikes. This manual includes detailed step-by-step instructions, black and white photographs, as well as wiring diagrams. All procedures in this manual were performed by an experienced dealer-trained Kawasaki technician.

Included in your purchase is 1 year of access to the full color Cyclepedia Online version, along with tech support for FREE!

Years and Models Covered

• 2010 Kawasaki KLX110 KLX110L
• 2011 Kawasaki KLX-110 KLX-110L
• 2012 Kawasaki KLX110/L
• 2013 Kawasaki KLX110/L
• 2014 Kawasaki KLX110/L
• 2015 Kawasaki KLX110/L
• 2016 Kawasaki KLX110/L
• 2017 Kawasaki KLX110/L
• 2018 Kawasaki KLX110/L
• 2019 Kawasaki KLX110/L
• 2020 Kawasaki KLX110/L

Table of Contents

• Periodic Maintenance
• Quick Reference
• External Components
• Fuel System
• Engine
• Final Drive
• Front Brake
• Rear Brake
• Wheels
• Front Suspension
• Steering
• Rear Suspension
• Electrical System
