2008 - 2020 Yamaha WR250R & WR250X Cyclepedia Motorcycle Service Manual

This Cyclepedia Press motorcycle service manual provides repair information for Yamaha WR250R & WR250X motorcycles. This manual includes detailed step-by-step instructions, black and white photographs, as well as wiring diagrams. All procedures in this manual were performed by an experienced technician.

Included in your purchase is 1 year of access to the full color Cyclepedia Online version, along with tech support for FREE!

Years and Models Covered

• 2008 Yamaha WR250RX motorcycles
• 2008 Yamaha WR250XX motorcycles
• 2009 Yamaha WR250RY motorcycles
• 2009 Yamaha WR250XY motorcycles
• 2010 Yamaha WR250RZ motorcycles
• 2010 Yamaha WR250XZ motorcycles
• 2011 Yamaha WR250RAL/RACL motorcycles
• 2011 Yamaha WR250XACW/WR250XAW motorcycles
• 2012 Yamaha WR250RB
• 2013 Yamaha WR250RD motorcycles
• 2014 Yamaha WR250RE motorcycles
• 2015 Yamaha WR250RF motorcycles
• 2016 Yamaha WR250RG motorcycles
• 2017 Yamaha WR250RH motorcycles
• 2018 Yamaha WR250R motorcycles
• 2019 Yamaha WR250R motorcycles
• 2020 Yamaha WR250R motorcycles (last year of production)

Table of Contents

• Periodic Maintenance
• Cooling System
• Fuel System
• External Components
• Engine
• Final Drive
• Front Brakes
• Rear Brakes
• Wheels
• Steering
• Front Suspension
• Rear Suspension
• Electrical System
• Quick Reference
