2004 - 2006 Harley-Davidson XL883 & XL1200 Sportster Cyclepedia Motorcycle Service Manual

This Cyclepedia Press motorcycle service manual provides repair information for Harley-Davidson XL883 & XL1200 motorcycles. This manual includes detailed step-by-step instructions, black and white photographs, as well as wiring diagrams. All procedures in this manual were performed by an experienced Honda dealer-trained motorcycle technician.

Included in your purchase is 1 year of access to the full color Cyclepedia Online version, along with tech support for FREE!

Years and Models Covered

• 2004 Harley-Davidson XL883C Sportster Custom
• 2004 Harley-Davidson XL883 Sportster
• 2004 Harley-Davidson XL1200R Sportster Roadster
• 2004 Harley-Davidson XL1200C Sportster Custom
• 2005 Harley-Davidson XL883L Sportster Low Rider
• 2005 Harley-Davidson XL883C Sportster Custom
• 2005 Harley-Davidson XL883 Sportster
• 2005 Harley-Davidson XL1200R Sportster Roadster
• 2005 Harley-Davidson XL1200C Sportster Custom
• 2006 Harley-Davidson XL883R Sportster
• 2006 Harley-Davidson XL883C Sportster Custom
• 2006 Harley-Davidson XL883 Sportster/Low
• 2006 Harley-Davidson XL1200R Sportster Roadster
• 2006 Harley-Davidson XL1200L Sportster Low
• 2006 Harley-Davidson XL1200C Sportster Custom

Table of Contents

• External Components
• Periodic Maintenance
• Cooling System
• Fuel System
• Exhaust System
• Clutch
• Engine Top End
• Engine Bottom End
• Engine Removal & Installation
• Front Wheel
• Rear Wheel
• Steering
• Front Suspension
• Rear Suspension
• Front Brake
• Rear Brake
• Final Drive
• Electrical System
