GM THM 4L60-E 1993 - 2015 Transmission Rebuild Manual
Item Number: 83-4L60-E
Weight: 1 lbs.
Publisher: Automatic Transmission Service Group (ATSG)
Softcover: 112 Pages
Dimensions: 8.5 x 10.5 x 0.4 inches
FREE SHIPPING on all Orders in USA over $200.00.


Coverage: Many General Motors full size rear wheel drive vehicles from 1993 - 2015.

The GM 4L60-E began in 1993 with medium duty trucks. It was then placed in passenger cars in 1994, with 2015 being its last year of production. This TechTran Manual serves as the complete overhaul instructions of the 4L60-E with all the needed specifications and sub-component rebuild procedures. Included are assembly, dis-assembly, diagnosis, troubleshooting, and electronic controls and operations. Note: There have been many engineering changes to this transmission since its introduction. The Green Update Manual provides the many changes that took place throughout these years. Changes made to the case, the pump and the addition of the Input Shaft Speed Sensor are some of what can be found in the "Update Handbook" - P/N 83-4L60ETM-U1.

Manual Contents:
  • Application & Solenoid Chart
  • Internal Electronic Controls
  • Shift Speed Chart
  • Line Pressure Check
  • Trouble Shooting Charts
  • Diagnostic Trouble Codes
  • Wiring Schematic
  • Transmission Disassembly
  • Transmission Reassembly
  • Updated Low/Reverse Piston
  • Updated Pressure Regulator Valve
  • Spacer Plate Screen Location
  • Checkball Locations
  • Checkball Pressure Switch Assembly
  • Model Application Chart
  • Updated Oil Filter Seal
  • Torque Specifications
  • Solenoid Resistance Chart
  • Special Tools
