Ford 5R55E Automatic Transmission ATSG Rebuild Overhaul Manual
Item Number: 83-5R55ETM
Weight: 1 lbs.
Publisher: Automatic Transmission Service Group
Softcover: Approx. 120 pages
Dimensions: 8.5 x 11.0 x 0.2 inches
FREE SHIPPING on all Orders in USA over $200.00.


The 5R55E Transmission is produced by Ford Motor Company and was introduced in the 1997 model year. It is the first 5 speed automatic found in domestic vehicles. It is currently found in the 1997 Aerostar Van, 1997-2001 Ranger Trucks (both 2WD & 4WD), and the 1997-2001 Explorer vehicles, equipped with the 4.0L engine.

This manual can also be used to rebuild the 5R44E transmission found in later model Ford Rangers and other models. The 5R55E unit is very similar to the 4R44E, but has a different computer strategy. Many of the parts between the 4R44E and the 5R55E units may look the same, but are not interchangeable.

Note: This manual cannot be used to rebuild the 4R44E transmission.

Contents:

  • General Description
  • Exploded Transmission Views
  • Electrical Components
  • Digital Transmission Range Sensor Values
  • Trouble Code Description
  • Transmission Disassembly
  • Valve Body
  • Checkball Locations
  • Oil Pump Assembly
  • Clutch Drums
  • Overdrive Planetary
  • Torque Converter
  • Transmission Assembly
  • Torque Specifications
