CLYMER REPAIR MANUAL

Models Covered:

• 2000-2012 SUZUKI DR-Z400E
• 2000-2012 SUZUKI DR-Z400S
• 2005-2012 SUZUKI DR-Z400SM

Every Clymer contains hundreds of original photographs and illustrations developed from a complete disassembly and assembly of the Motorcycle. This, in addition to extensive research, allows Clymer to achieve an un-matched level of detail, accuracy & clarity.

The step-by-step instructions and two column text with large print are user friendly, bold figure numbers make it easy to quickly match instructions with illustrations and photos. Thumb tabbed chapters, numbered table of contents and extensive index make it possible to locate the desired section quickly.

Contents:

• Quick Reference Data
• General Information
• Troubleshooting
• Lubrication, Tune-up & Maintenance
• Engine Top End
• Engine Lower End
• Clutch, External Shift Mechanism and Lubrication System
• Transmission, and Internal Shift Mechanism
• Fuel System
• Electrical System
• Cooling System
• Wheels, Tires and Drive Chain
• Front suspension and Steering
• Rear Suspension
• Breaks
• Body
• Index
• Color Wiring Diagrams
