1971 - 1975 Honda CB500 Factory Service Manual - OEM

This a Genuine, OEM Factory Service Manual. This manual describes the detailed, step-by-step service, repair, troubleshooting & overhaul procedures for the 1971 - 1975 Honda CB500 Motorcycles. This is the same manual used in your local Honda dealership by certified Honda Technicians.

MODEL COVERAGE:

• Honda CB500: 1971 - 1975

TYPICAL TABLE OF CONTENTS:

• General Information
• Frame / Body Panels / Exhaust System
• Maintenance
• Lubrication System
• Fuel System
• Cooling System
• Engine Removal / Installation
• Cylinder Head / Valves
• Cylinder / Piston
• Drive and Driven Pulleys / Clutch
• Alternator / Starter Clutch
• Crankcase / Crankshaft
• Front Wheel / Suspension / Steering
• Rear Wheel / Brake / Suspension
• Hydraulic Disc Brake
• Battery / Charging System
• Ignition System
• Electric Starter
• Lights / Meters / Switches
• Wiring Diagram
• Troubleshooting
• Index
