$39.95 $32.95

Item Number: 83-722-3-4-TM
Weight: 1 lbs.
Publisher: Automatic Transmission Service Group
MINI CD-ROM
FREE SHIPPING on all Orders in USA over $200.00.


Mercedes first introduced the "722.3 / 722.4" models in the year 1980. The 722.3 is found in most Mercedes models. The 722.4 is found in the 190 Mercedes models. This manual covers teardown & assembly procedures for both the 772.3 / 722.4 Mercedes Transmission (identified by the 6 bolt pan). This manual also covers the differences between the units in the valve body & governor. The basic internal components, such as the pump, gaskets, drums, clutches & bands are the same. This manual includes both the original manufacturers information along with some of the engineering changes and updates.

Contents:

  • Application & cross section
  • Test Connections
  • Road test
  • Valve Body removal
  • Valve Body Teardown
  • Valve Body 722.4
  • Removal Rear Pump & Governor
  • Governor 722.3 / 722.4
  • Transmission Removal & Replacement
  • Teardown of Transmission
  • Teardown Front Pump
  • Teardown Planetary Components
  • K1 Clutch
  • K2 Clutch
  • Troubleshooting
  • Technical Bulletins & Updates
