Mercedes, Jaguar, Chrysler 722.6 ATSG Transmission Rebuild Manual - Softcover
Item Number: 83-722-6
Weight: 1 lbs.
Publisher: Automatic Transmission Service Group
Softcover: Approx. 100 pages
Dimensions: 11.0 x 8.5 x 0.25 inches
FREE SHIPPING on all Orders in USA over $200.00.




722.6 and NAG1 (for Dodge/Chrysler) Rebuild Edition Manual

This manual will be extremely helpful in successfully repairing this trans as it is now in numerous Chrysler applications as well as Mercedes. This manual is also loaded with update information as this trans has been with us since 1997. There are also many helpful assembly tips along the way.

This manual provides techniques required to perform transmission repairs, overhaul, diagnosis & testing.

Contents:

  • Transmission Identification
  • General Description
  • Internal Component Identification and Locations
  • Solenoid Application Chart
  • Fluid Requirements and Checking Procedure
  • Oil Level Control
  • Solenoid Locations and Identification
  • Solenoid Operation
  • Electrical Conductor Plate
  • Case Connector Terminal Identification
  • Park / Neutral Contact and Fluid Temp Sensor
  • N2 and N3 Input Speed Sensors
  • Transmission Control Module and Locations
  • TCM Connectors and Terminal Identification
  • Solenoid Resistance Chart
  • Shift Lever Assembly
  • Transmission Range Recognition Switch
  • Wiring Schematics
  • Diagnostic Trouble Code Description
  • Torque Converter Operation
  • Checkball and Small Parts Locations
  • Hydraulic Passage Identification
  • F-1 and F-2 Freewheel Directions
  • Transmission Disassembly
  • Component Rebuild
  • Transmission Final Assembly
  • Torque Specifications
