$51.95 $35.95

2004 - 2013 Harley-Davidson XL883 & XL1200 Sportster Clymer Repair Manual
Item Number: M4274-1599696428
Weight: 3 lbs.
Publisher: Clymer Manuals
Softcover: 616 pages
Dimensions: 8.5 x 11.0 x 1.5 inches
FREE SHIPPING on all Orders in USA over $200.00.


Clymer Superbike Service, Repair & Maintenance Manual

Every Clymer contains hundreds of original photographs and illustrations developed from a complete disassembly and assembly of the motorcycle. This, in addition to extensive research, allows Clymer to achieve an un-matched level of detail, accuracy & clarity. The step-by-step instructions and two column text with large print are user friendly, bold figure numbers make it easy to quickly match instructions with illustrations and photos. Thumb tabbed chapters, numbered table of contents and extensive index make it possible to locate the desired section quickly.

Models Covered:

  • 2004-2013 HARLEY-DAVIDSON XL1200C Sportster Custom
  • 2004-2011 HARLEY-DAVIDSON XL1200L Sportster Low
  • 2007-2012 HARLEY-DAVIDSON XL1200N Sportster Nightster
  • 2004-2009 HARLEY-DAVIDSON XL1200R Sportster
  • 2012-2013 HARLEY-DAVIDSON XL1200V Sportster 72 Seventy-Two
  • 2010-2013 HARLEY-DAVIDSON XL1200X Sportster 48 Fourty-Eight
  • 2004-2009 HARLEY-DAVIDSON XL883 Sportster
  • 2004-2010 HARLEY-DAVIDSON XL883C Sportster Custom
  • 2004-2013 HARLEY-DAVIDSON XL883L Sportster Low
  • 2009-2013 HARLEY-DAVIDSON XL883N Sportster Iron
  • 2004-2013 HARLEY-DAVIDSON XL883R Sportster
  • ****** Does Not Include XR1200 *******

Contents:

  • CHAPTER ONE - GENERAL INFORMATION
  • CHAPTER TWO - TROUBLESHOOTING
  • CHAPTER THREE - LUBRICATION, MAINTENANCE AND TUNE-UP
  • CHAPTER FOUR - ENGINE TOP END
  • CHAPTER FIVE - ENGINE LOWER END
  • CHAPTER SIX - PRIMARY DRIVE, CLUTCH AND EXTERNAL SHIFT MECHANISM
  • CHAPTER SEVEN - TRANSMISSION AND INTERNAL SHIFT MECHANISM
  • CHAPTER EIGHT - FUEL, EMISSION CONTROL AND EXHAUST SYSTEMS
  • CHAPTER NINE - ELECTRICAL SYSTEM
  • CHAPTER TEN - WHEELS, TIRES AND DRIVE BELT
  • CHAPTER ELEVEN - FRONT SUSPENSION AND STEERING
  • CHAPTER TWELVE - REAR SUSPENSION
  • CHAPTER THIRTEEN - BRAKES
  • SUPPLEMENT 2007-2013 SERVICE INFORMATION
  • INDEX
  • COLOR WIRING DIAGRAMS
